Waxy Casts in Urine Sediment Microscopy: Morphology & Diagnosis

Explore the morphology of waxy casts in urine sediment microscopy in a patient with renal failure and proteinuria. Understand their formation and diagnostic significance.

Anna Feditskaya 1 min December 26, 2025

Native urine preparation, wide waxy cast with deep transverse notches

Native urine sediment preparation, fragment of a waxy cast with sharp edges

Native urine sediment preparation, wide short waxy cast with a fracture

Native urine sediment preparation, fragments of wide waxy and granular casts

Native urine sediment preparation, waxy cast with a bay-like indentation on the edge

Native urine sediment preparation, large waxy cast with fine cracks

Native urine sediment preparation, waxy casts of high optical density

Native urine sediment preparation, long terminal waxy cast

Patient from the Department of Nephrology and Hemodialysis. Urine sediment microscopy. Waxy casts. Proteinuria 3.0 g/L.

Waxy casts are dense, homogeneous, wax-candle-like fragments, clearly contoured, straight and convoluted, short and long cylindrical formations. The casts may have cracks and bay-like indentations along their contour. Wide waxy casts form due to the stasis of hyaline and granular casts in dilated distal tubules and collecting ducts of the kidneys. These casts are called terminal casts.

Waxy casts are usually found in nephrotic syndrome of various etiologies. The presence of terminal casts in urine sediment is characteristic of chronic renal failure.

🙏 Photos and description kindly provided by biologist Anna Feditskaya, Luhansk
